Links between SysML and Excel® make it easy to import and export data, generate SysML instances, and create reports and generate graphs and charts. Mathematica® and PlayerPro® ( Wolfram Research), OpenModelica®, and MATLAB® Symbolic Math Toolbox™ ( MathWorks) can be used as math solvers. Select created Interface Block as Proxy Port type.ParaMagic® plugin for MagicDraw makes SysML models come alive! By executing constraint relationships in SysML parametric diagrams, systems engineers can run simulations and trade studies for complex systems from concept through final test.Create Interface Block in the model and specify its Flow Properties.In the SysML Internal Block Diagram, create Proxy Ports.

How to define Blocks> How to create Block internal structure >

Create a Block and decompose it in the SysML Internal Block Diagram.

The Gra圜odeIB Interface Block is a type of Proxy Ports. It means the Proxy Port that is typed by Gra圜odeIB Interface Block can send and receive Flow Items of Pulse Signal. In the following figure, the chanel2 Proxy Port is typed by Gra圜odeIB Interface Block which contains two Flow Properties of Pulse Signal: out a and out b. Full Ports cannot be behavioral in the UML sense of standing in for the owning object, because they handle features themselves, rather than exposing features of their owners, or internal parts of their owners. Proxy Ports are always typed by Interface Blocks, a specialized kind of Block that has no behaviors or internal parts.

Proxy Ports define the boundary by specifying which features of the owning Block or Part Properties are visible through external connectors, while Full Ports define the boundary with their own features. They are properties with a type that specifies features available to the external entities via Connectors to the ports.

Ports are points at which external entities can connect to and interact with a Block in different or more limited ways than connecting directly to the Block itself.
